Performance Verification 13-7
2. Select the multimeter DC volts measuring function, and enable auto-ranging.
3. Select Channel #1 by pressing the
â–²
and
â–²
keys to toggle between Channel #1 and
Channel #2. Make sure the Model 2306 output is turned on.
4. Verify output voltage accuracy for each of the voltages listed in Table 13-2. For each test
point:
• Set the Model 2306 output voltage to the indicated value.
• A value of current compliance of 0.25A is sufficient.
• Allow the reading to settle.
• Verify that the multimeter reading is within the limits given in the table.
1. Repeat steps 1 through 4 for Channel #2 (use the
â–²
and
â–²
keys to toggle between
Channel #1 and Channel #2).
Table 13-2
Output voltage accuracy limits
Model 2306 output
volta
ge setting
Output voltage limits
(2 Years, 18°C-28°C)
5.00V 4.9945 to 5.0055V
10.00V 9.992 to 10.008V
15.00V 14.9895 to 15.0105V
