COMPONENT ACCESS
n
4-1
Section 4:
Component Access
This secon provides service parts access, removal and
installaon informaon concerning 2013 New Design 15” Ice
Maker. Refer to the Repair Parts List for your specic model
to see what parts are available for ordering. Access may be
shown to some assemblies that can be disassembled further.
n Front Grille Components
n Leveling Legs
n Access the Water Valve and Tech Sheet
n Removing the Water Valve
n Ice Bin Components
n Door Removal/Reversal - Side Swing Only
n Ice Bin Door Removal
n Door Gasket Service
n Removing Reservoir Cover
n Heater Grid Removal
n Removing the Bin Thermistor
n Accessing Ice Bin Electrical Connecons
n Removing Reservoir and Pumps
n Removing Recirculaon Pump
n Removing Water Level Sensor
n Removing Drain Pump
n Ice Maker Top Components
n Removing Top
n Accessing the Control Compartment
n Removing Transformer
n Removing User Interface Board
n Removing Main Control Board
n Machine Compartment Components
n Accessing Machine Compartment
n Fan Inductor and Thermistor
n Condensate Pump Removal
n Raising Cabinet to Access Components
