INSTALLING THE BATTERY PACK
Note: Because the battery pack is provided uncharged, you must charge the battery pack
before using it with the transceiver. To charge the battery pack, refer to “CHARGING THE
BATTERY PACK ” {page 3}.
1 To install the battery pack, align the base of the
battery pack with the transceiver, then press
the battery pack into place until the lock lever is
secure.
2 To remove the battery pack, push the lock lever
up, then pull the battery pack away from the
transceiver.
Lock lever
Lock lever
INSTALLING THE BELT CLIP
If desired, you can install the supplied belt clip to the transceiver.
1 Remove the battery pack, as described above.
2 To install the belt clip, align the guides of the
belt clip with the grooves on the rear of the
battery pack, then slide the belt clip into place
until the lock lever is secure.
3 To remove the belt clip, push the lock lever
towards the transceiver while sliding the belt
clip up.
Belt clip
Lock lever
