• Firmware updates are usually timed to take place during the evening in North America.
• Depending on what part of the BMS is being updated, either the red “ALARM” LED will
flash by itself, or the red “ALARM” LED will flash along with the two bottom red LEDs in
the State of Charge bar.
• Firmware updates include BMS improvements to:
o HAB™ to HAB™ Communications
o Cycle Counting
o State of Charge Calculation
o Other BMS functions as needed.
• The WiFi adapter firmware cannot be updated.
5.4. Starting the HAB™ for the first time
1. Turn on (close) the inverter main DC breaker. If your inverter does not have its own
power switch, and if completing the circuit between the inverter and the battery will
start the inverter, please start with step #2 and save this step for last.
2. Turn on (close) the battery breaker on the side of the HAB™.
3. Press the power button on the control panel at least three seconds. The green RUN LED
will flash five times, and then both the HAB™ control panel LCD screen and the state of
charge light bar will light up.
4. Wait five seconds for the HAB™ battery management system to pre-charge.
5. If you are installing and commissioning more than one HAB™, after you have made the
electrical and communication connections and set the HAB™ addresses, perform steps 2
- 4 for each HAB™, starting with the first follower HAB™, until all HAB™ units are
energized.
6. Turn on the inverter.
If there are no alarms, the green RUN LED will be lit, and the control panel will be populated
with information about the running condition of your HAB™. The control panel will remain lit for
5 minutes and then go blank. If you briefly (less than three seconds) press the HAB™’s power
button, the control panel will again light for 5 minutes.
If there is an alarm condition, the RED Alarm LED will light, plus one or more of the alarm or
protection state indicators at the right of the control panel will light. Please see the BMS Alarm
and Protection table for details.
To turn off the HAB™, press the power button for three seconds. The run LED will flash five
times, then the control panel and the state of charge bar will go dark. The HAB™ is now off.
5.5. Monitoring
You can monitor the HAB™ using either the front control panel or the “KiloVault HAB iT” mobile
application. There are both Android and iOS versions of the app. The iOS app requires iOS 10 or
above. The Android app requires Android 5.0 (Lollypop) and above. The apps are available from
