Electrical System
98
24 690 01 Rev. KKohlerEngines.com
FUSES
This engine has 3 blade type automotive fuses.
Replacement fuses must have same rating as blown
fuse. Use fuse chart below to determine correct fuse.
Wire Color Fuse Rating
2 Purple Wires 30-amp Fuse
1 Red Wire w/Black Stripe
1 Red Wire w/White Stripe
10-amp Fuse
2 Red Wires 10-amp Fuse
Fuse Replacement
1. Shut engine off and remove key.
2. Locate fuse holders.
3. Remove fuse cover and pull out fuse.
4. Inspect fuse for a solid fusible link or a broken
fusible link. Replace fuse if fusible link is broken. If
you are not sure if fusible link is broken, replace
fuse.
5. Insert fuse into fuse holder until it is seated properly.
Install fuse cover.
