OPERATION TRANSPORTATION
3-127
(For D61PX)
q Raise blade (5) height (B) 30 - 40 cm (1.2 - 1.6 in) from the ground.
q Pass the wire rope at the front within the range (A) between the center of the front idler and the rear edge,
pass it under the undercover, and bring it out to the opposite side.
q Fit protector (1) at the edge to protect the wire rope.
q Fit the wire ropes at the rear to both left and the right pivot shafts (2).
