MAINTENANCE
SERVICE PROCEDURE
CLEAN BRAKE DRAIN TUBE
WARNING
If compressed air scattered around dust and debris, there is danger of injury. Always wear protective equipment such as
protective glasses and mask.
A brake drain tube is installed to each wheel. Clean the tubes of all the wheels.
1. Remove cover (1), then remove brake drain tube (2).
2.
After removing the tube, use compressed air to blow out the soil and dirt from the tube.
3.
Install brake drain tube (2) and cover (1).
Front (left and right: 2 places)
Center (left and right: 2 places)
Rear (left and right: 2 places)
4 - 41
