140-3 SERIES
GENERAL WEIGHT TABLE
(9)
WEIGHT TABLE
Unit : kg
No. Item Main item SA6D140E-3 SAA6D140E-3
1 Turbocharger Komatsu KTR110L 23 23
2 Cylinder head assembly
Cylinder head, valve, valve
spring
22.5 x 6 22.5 x 6
3 Cylinder block assembly
Cylinder block, bearing cap,
cylinder liner
480 480
4 Front cover 43 43
5Oil pan
D155AX-5
WA500-3
30
PC750-6,PC750-7
PC800-6,PC800-7
PC1800-6
36
DCA400SSK
(DENYO
generator)
62
HD325-6
HM350-1
HM400-1
28
6 Flywheel assembly Flywheel ring gear
D155AX-5
WA500-3
60
PC750-6,PC750-7
PC800-6,PC800-7
PC1800-6
60
DCA400SSK
(DENYO
generator)
114
HD325-6
HM350-1
HM400-1
47
7 Flywheel housing assembly
D155AX-5 60
PC750-6,PC750-7
PC800-6,PC800-7
PC1800-6
59
WA500-3
55
DCA400SSK
(DENYO
generator)
64
HD325-6
HM350-1
HM400-1
59
8 Crankshaft assembly Crankshaft, crankshaft gear 136 136
9 Camshaft assembly Camshaft, cam gear thrust plate 19 19
10
Piston, connecting
rod assembly
Piston, piston ring, piston pin,
connecting rod
10.7 x 6 10.7 x 6
11 Oil pump 6.5 6.5
12 Fuel supply pump 13 13
13 Water pump 17 17
14 Alternator
24V 35A 9.5 9.5
24V 50A 11 11
24V 75A 12.5 19
24V 90A —
PC800-6 (USA)
PC800-7 (USA)
PC1800-6 (USA)
19
15 Starting motor
24V 7.5kW 15.5 15.5
24V 11kW 18 18
16 Air compressor 11 11
17 Aftercooler assembly 45
PC750-6,PC750-7
PC800-6,PC800-7
PC1800-6
37
HD325-6
HM350-1
HM400-1
35
