11 Maintenance – lubrication chart
Pos: 110.23.2 /Ü berschriften/Ü berschriften 2/P-T/ Spezielle Sic herheitshin weise @ 0\mod_ 11966604957 60_78.doc @ 9134
11.1 Special Safety Instructions
Pos: 110.23.3 / BA/Sicherheit/G efahrenhin weise/Ladewagen/G efahr Wartung allgemein @ 0\mod_11998 84069862_78.d oc @ 36704
Danger! - When performing repair, maintenance or cleaning work on the machine, or in
the case of technical intervention, drive elements may start moving.
Effect: Danger to life, injuries or damage to the machine.
• Switch off the tractor engine and remove the ignition key
• Secure the machine and tractor against the possibility of rolling back.
• Switch off the PTO and disengage it
• After the repair, maintenance and cleaning work or technical interventions are completed,
mount all protective coverings and safety devices properly again.
• Avoid skin contact with oils, greases, cleaning agents and solvents.
• In the event of injuries or burns due to oils, cleaning agents or solvents, contact a
physician immediately.
• All other safety instructions must also be followed to avoid injuries and accidents.
Pos: 110.23.4 /Ü berschriften/Ü berschriften 2/F- J/Gelenkwelle @ 0\mod_1 19978187979 4_78.doc @ 345 42
11.2 PTO shaft
Pos: 110.23.5 / BA/Wartung/Sc hwader/Schmier plan/Abschmi eren Gelenkwell e Schwader S W 700_800_ 900 @ 4\mod_12 12144519316 _78.doc @ 85 655
Fig. 26:
Lubricate the PTO shafts at the intervals indicated in the drawing with a multi-purpose grease.
Follow the operating instructions of the PTO shaft manufacturer.
