KTM 125 Duke 2017 User Manual

15 ELECTRICAL SYSTEM 129
15.1 Daytime running light (DRL)
F00850-11
Warning
Danger of accidents When visibility is poor, the daytime running light is not a sub-
stitute for the low beam.
Automatic switching between the daytime running light and low beam may only be
partially available when visibility is significantly impaired due to fog, snow or rain.
– Ensure that the appropriate type of lighting is always selected.
– If necessary switch off the daytime running lights using the menu before going
on a ride or when stopped so that the low beam is switched on permanently.
– Note the legal regulations regarding the daytime running light.
The daytime running light (DRL)
1
is integrated in the main headlight.
The daytime running light (DRL
) must only be switched on when visibility conditions are
good.
Activate the daytime running light (DRL
) in the combination instrument.
Control is provided by the brightness sensor in the combination instrument. When visibility
conditions are good, the low beam is switched off and the daytime running light is switched
on.
Info
The position light
2
lights up with all types of lighting.

KTM 125 Duke 2017 Specifications

General

Displacement	124.7 cc
Bore x Stroke	58 mm x 47.2 mm
Compression Ratio	12.6:1
Power	15 hp (11 kW) @ 10, 000 rpm
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Rear Suspension	WP monoshock
Seat Height	830 mm
Ground Clearance	185 mm
Dry Weight	137 kg
Engine Type	Single cylinder, 4-stroke
Torque	12 Nm @ 8, 000 rpm
Frame	Steel trellis frame, powder coated
Front Suspension	WP upside-down Ø 43 mm
Front Brake	Four-piston radial fixed caliper, brake disc
Rear Brake	Single-piston floating calliper, brake disc
Front Tire	110/70 x 17
Rear Tire	150/60 x 17
ABS	Bosch 9MB Two Channel ABS
