KTM 125 Duke 2017 User Manual

7 COMBINATION INSTRUMENT 57
7.17.14 Favourites
F00814-01
Condition
• The motorcycle is stationary.
– Press the SET button when the menu is closed.
– Press the UP or DOWN button until Settings is marked. Press the SET button to open the
menu.
– Press the UP or DOWN button until Favourites is marked. Press the SET button to open
the menu.
– Press the UP or DOWN button to activate the menu item and select it with the SET but-
ton.
Up to eight items of information can be selected in the Favourites menu.
7.17.15 Quick Selector 1
F00815-01
Condition
• The motorcycle is stationary.
– Press the SET button when the menu is closed.
– Press the UP or DOWN button until Settings is marked. Press the SET button to open the
menu.
– Press the UP or DOWN button until Quick Selector 1 is marked. Press the SET button to
open the menu.
– Press the UP or DOWN button to activate the menu item and select it with the SET but-
ton.
Information can be selected in the Quick Selector 1 menu.
When the menu is closed, the Quick Selector 1 menu is opened by pressing the UP button.

KTM 125 Duke 2017 Specifications

General

Displacement	124.7 cc
Bore x Stroke	58 mm x 47.2 mm
Compression Ratio	12.6:1
Power	15 hp (11 kW) @ 10, 000 rpm
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Rear Suspension	WP monoshock
Seat Height	830 mm
Ground Clearance	185 mm
Dry Weight	137 kg
Engine Type	Single cylinder, 4-stroke
Torque	12 Nm @ 8, 000 rpm
Frame	Steel trellis frame, powder coated
Front Suspension	WP upside-down Ø 43 mm
Front Brake	Four-piston radial fixed caliper, brake disc
Rear Brake	Single-piston floating calliper, brake disc
Front Tire	110/70 x 17
Rear Tire	150/60 x 17
ABS	Bosch 9MB Two Channel ABS
