KTM 125 Duke 2017 User Manual

22 TECHNICAL DATA 173
Screw, camshaft drive sprocket M8 32 Nm (23.6 lbf ft) Loctite
®
243™
Screw, return spring, quick shifter M8 20 Nm (14.8 lbf ft) Loctite
®
243™
Stud, exhaust flange M8 22 Nm (16.2 lbf ft) –
Cylinder head screw M10 Step 1
25 Nm (18.4 lbf ft)
Step 2
50 Nm (36.9 lbf ft)
Thread is oiled, head flat is
greased
Oil pressure sensor M10 14 Nm (10.3 lbf ft) –
Rotor screw M10 70 Nm (51.6 lbf ft) Loctite
®
243™
Water temperature sensor M10 14 Nm (10.3 lbf ft) –
Screw plug, cam lever axis M10x1 10 Nm (7.4 lbf ft) –
Spark plug M12 15 Nm (11.1 lbf ft) –
Nut, inner clutch hub M14LH 60 Nm (44.3 lbf ft) Loctite
®
243™
Nut, primary gear/timing chain sprocket M14 55 Nm (40.6 lbf ft) Loctite
®
243™
Oil drain plug M24x1.5 15 Nm (11.1 lbf ft) –
22.3 Capacities
22.3.1 Engine oil
Engine oil 1.5 l (1.6 qt.) External temperature: 0…
50 °C (32… 122 °F)
Engine oil (SAE 15W/50)
(
p. 186)
External temperature: −10…
40 °C (14… 104 °F)
Engine oil (SAE 10W/40)
( p. 186)
22.3.2 Coolant
Coolant 1 l (1 qt.) Coolant ( p. 185)

KTM 125 Duke 2017 Specifications

General

Displacement	124.7 cc
Bore x Stroke	58 mm x 47.2 mm
Compression Ratio	12.6:1
Power	15 hp (11 kW) @ 10, 000 rpm
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Rear Suspension	WP monoshock
Seat Height	830 mm
Ground Clearance	185 mm
Dry Weight	137 kg
Engine Type	Single cylinder, 4-stroke
Torque	12 Nm @ 8, 000 rpm
Frame	Steel trellis frame, powder coated
Front Suspension	WP upside-down Ø 43 mm
Front Brake	Four-piston radial fixed caliper, brake disc
Rear Brake	Single-piston floating calliper, brake disc
Front Tire	110/70 x 17
Rear Tire	150/60 x 17
ABS	Bosch 9MB Two Channel ABS
