KTM 125 Duke 2017 User Manual

6 CONTROLS 24
6.4.2 Light switch
F00719-10
Light switch
1
is fitted on the left side of the handlebar.
Possible states
Low beam on – Light switch in position
A
. In this position, the low beam
and the tail light are switched on.
High beam on – Push the light switch to position
B
. In this position, the
high beam and the tail light are switched on.
Headlight flasher – Push the light switch into position
C
.
6.4.3 Menu switch
F00721-10
The menu switch is fitted in the middle of the left combination switch.
The menu buttons are used to control the display on the combination instrument.
Button
1
is the UP button.
Button
2
is the DOWN button.
Button
3
is the SET button.
Button
4
is the BACK button.

KTM 125 Duke 2017 Specifications

General

Displacement	124.7 cc
Bore x Stroke	58 mm x 47.2 mm
Compression Ratio	12.6:1
Power	15 hp (11 kW) @ 10, 000 rpm
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Rear Suspension	WP monoshock
Seat Height	830 mm
Ground Clearance	185 mm
Dry Weight	137 kg
Engine Type	Single cylinder, 4-stroke
Torque	12 Nm @ 8, 000 rpm
Frame	Steel trellis frame, powder coated
Front Suspension	WP upside-down Ø 43 mm
Front Brake	Four-piston radial fixed caliper, brake disc
Rear Brake	Single-piston floating calliper, brake disc
Front Tire	110/70 x 17
Rear Tire	150/60 x 17
ABS	Bosch 9MB Two Channel ABS
