KTM 125 Duke 2017 User Manual

7 COMBINATION INSTRUMENT 54
7.17.9 General Info
F00806-01
– Press the SET button when the menu is closed.
– Press the UP or DOWN button until Info is marked. Press the SET button to open the
menu.
– Press the UP or DOWN button until General Info is marked. Press the SET button to open
the menu.
Date shows the date.
ODO shows the total distance covered.
Battery indicates the battery voltage.
7.17.10 Trip 1
F00807-01
– Press the SET button when the menu is closed.
– Press the UP or DOWN button until Info is marked. Press the SET button to open the
menu.
– Press the UP or DOWN button until Trip 1 is marked. Press the SET button to open the
menu.
Trip 1 shows the distance since the last reset, such as between two refueling stops. Trip 1 is
running and counts up to 9999.
ØCons1 indicates the average fuel consumption based on Trip 1.
ØSpeed1 indicates the average speed based on Trip 1 and Trip Time1.
Trip Time1 shows the journey time on the basis of Trip 1 and runs as soon as a speed signal
is received.
Fuel Range indicates the possible distance you can cover with the fuel reserve.
Press and hold the
SET button for 3-5
seconds.
All entries in the Trip 1 menu are reset.

KTM 125 Duke 2017 Specifications

General

Displacement	124.7 cc
Bore x Stroke	58 mm x 47.2 mm
Compression Ratio	12.6:1
Power	15 hp (11 kW) @ 10, 000 rpm
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Rear Suspension	WP monoshock
Seat Height	830 mm
Ground Clearance	185 mm
Dry Weight	137 kg
Engine Type	Single cylinder, 4-stroke
Torque	12 Nm @ 8, 000 rpm
Frame	Steel trellis frame, powder coated
Front Suspension	WP upside-down Ø 43 mm
Front Brake	Four-piston radial fixed caliper, brake disc
Rear Brake	Single-piston floating calliper, brake disc
Front Tire	110/70 x 17
Rear Tire	150/60 x 17
ABS	Bosch 9MB Two Channel ABS
