KTM 125 Duke 2017 User Manual

7 COMBINATION INSTRUMENT 45
7.11 Coolant temperature indicator
402808-01
The coolant temperature indicator consists of bars. The more bars that light up, the hotter
the coolant.
Info
When all bars light up, the following warning note ENGINE TEMP HIGH appears.
Possible states
• The engine is cold – Up to three bars light up.
• Engine warm – Four to five bars light up.
• Engine hot – Six to eight bars light up.
• Engine very hot – All eight bars light up red.
7.12 Fuel level display
402807-10
The fuel tank contents are shown in area
1
of the display.
The fuel level indicator consists of bars. The more bars are lit, the more fuel is in the fuel
tank.
Info
If the fuel level is getting low, the last segment flashes red and the following warn-
ing note also appears LOW FUEL.
The fuel level is displayed with a slight delay to prevent the indicator from con-
stantly moving while riding.
The fuel level display is not updated while the side stand is folded out or the emer-
gency off switch is switched off.
Once the side stand is folded up and emergency OFF switch is switched on, the fuel
level display is next updated after 2 minutes.
The fuel level display flashes if the combination instrument does not receive a signal
from the fuel level sensor.

KTM 125 Duke 2017 Specifications

General

Displacement	124.7 cc
Bore x Stroke	58 mm x 47.2 mm
Compression Ratio	12.6:1
Power	15 hp (11 kW) @ 10, 000 rpm
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Rear Suspension	WP monoshock
Seat Height	830 mm
Ground Clearance	185 mm
Dry Weight	137 kg
Engine Type	Single cylinder, 4-stroke
Torque	12 Nm @ 8, 000 rpm
Frame	Steel trellis frame, powder coated
Front Suspension	WP upside-down Ø 43 mm
Front Brake	Four-piston radial fixed caliper, brake disc
Rear Brake	Single-piston floating calliper, brake disc
Front Tire	110/70 x 17
Rear Tire	150/60 x 17
ABS	Bosch 9MB Two Channel ABS
