22 TECHNICAL DATA
146
22.2 Engine tightening torques
Oil nozzle for the clutch lubrication
(alternator cover sealing surface)
M4 0.8 Nm (0.59 lbf ft)
Screw, oil nozzle bent for piston
cooling
M4 2 Nm (1.5 lbf ft)
Loctite
®
243™
Crankshaft speed sensor screw and
cable retainer
M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Oil nozzle for piston cooling M5 2 Nm (1.5 lbf ft)
Loctite
®
243™
Oil nozzle for timing chain lubrica-
tion
M5 2 Nm (1.5 lbf ft)
Loctite
®
243™
Screw, bearing retainer M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, clutch spring retainer M5 6 Nm (4.4 lbf ft)
Screw, gear position sensor M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, lock washer, oil pump idler
gear
M5x10 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, locking lever M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, pressure pump cover M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, stator M5 6 Nm (4.4 lbf ft)
Loctite
®
2701™
Screw, suction pump cover M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Nut, water pump impeller M6 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, alternator cover M6x25 10 Nm (7.4 lbf ft)
Screw, balancer shaft fastening to
water pump cover
M6 10 Nm (7.4 lbf ft)
Loctite
®
222™
Screw, clutch cover M6x25 10 Nm (7.4 lbf ft)
Screw, clutch cover M6x55 10 Nm (7.4 lbf ft)
Screw, clutch slave cylinder M6 10 Nm (7.4 lbf ft)
Screw, cylinder head M6 10 Nm (7.4 lbf ft)
Screw, engine case M6x65 10 Nm (7.4 lbf ft)
Screw, engine case M6x80 10 Nm (7.4 lbf ft)
Screw, exhaust flange M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, oil filter cover M6 10 Nm (7.4 lbf ft)
Screw, shift drum locating M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift lever M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, starter motor M6 10 Nm (7.4 lbf ft)
Screw, tensioning rail M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
