KTM 500 EXC-F 2022 User Manual

23 TECHNICAL DATA
160
23.5 Electrical system
12-V battery HJTZ5S-FP‑C Lithium-ion battery
Battery voltage: 12 V
Nominal capacity: 2.0 Ah
Maintenance-free
Combination instrument battery CR 2430 Battery voltage: 3 V
Fuse 75011088005 5 A
Fuse 75011088010 10 A
Fuse 58011109120 20 A
Headlight HS1 / socket PX43t 12 V
35/35 W
Position light W5W / socket W2.1x9.5d 12 V
5 W
Indicator lamps W2.3W / socket W2x4.6d 12 V
2.3 W
Turn signal (All EU models) R10W / socket BA15s 12 V
10 W
Brake/tail light LED
License plate lamp LED
23.6 Tires
Validity Front tire Rear tire
(EXC‑F EU) 80/100 - 21 M/C 51M TT
MAXXIS Maxx Enduro
140/80 - 18 M/C 70R M+S TT
MAXXIS Maxx Enduro
(XCF‑W) 90/90 - 21 54M TT
Dunlop GEOMAX AT81F
110/100 - 18 64M TT
Dunlop GEOMAX AT81
(EXC‑F SIX DAYS EU) 90/90 - 21 M/C 54M M+S TT
Metzeler MCE 6 Days Extreme
140/80 - 18 M/C 70M M+S TT
Metzeler MCE 6 Days Extreme
The tires specified represent one of the possible series production tires. Additional information is available in
the Service section under:
KTM.COM
23.7 Fork
Fork article number 0797C162V401000
Fork WPXPLOR OC
Compression damping
Comfort 18 clicks
Standard 15 clicks
Sport 12 clicks
Rebound damping
Comfort 18 clicks
Standard 15 clicks
Sport 12 clicks
Spring preload - Preload Adjuster
Comfort +0
Standard +0

KTM 500 EXC-F 2022 Specifications

General

Bore x Stroke	95 mm x 72 mm
Starter	Electric starter
Transmission	6-speed
Cooling	Liquid cooled
Frame	Central double-cradle type 25CrMo4 steel
Front Suspension	WP XPLOR-USD, Ø 48 mm
Rear Suspension	WP XPLOR PDS shock absorber
Ground Clearance	355 mm
Seat Height	960 mm
ABS	No
Engine Type	Single-cylinder, 4-stroke
Fuel System	Keihin EFI, 42 mm throttle body
Front Brake	Disc brake
Rear Brake	Disc brake, 220 mm
Fuel Tank Capacity	8.5 liters
Weight (without fuel)	106.5 kg
Displacement	510.9 cm³
