6 CONTROLS
24
6.23 Unlocking the steering (All EU models)
400731-01
– Insert the key for the steering lock into the steering lock
( p. 23), turn it to the left, pull it out, and turn it to the
right. Pull out the key for the steering lock.
The handlebar can now be moved again.
Info
Never leave the key for the steering lock in the steering
lock.

Table of Contents

Other manuals for KTM 500 EXC-F 2022

Preview: Setup Instructions
Setup Instructions44 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KTM 500 EXC-F 2022 and is the answer not in the manual?

KTM 500 EXC-F 2022 Specifications

General IconGeneral
Bore x Stroke95 mm x 72 mm
StarterElectric starter
Transmission6-speed
CoolingLiquid cooled
FrameCentral double-cradle type 25CrMo4 steel
Front SuspensionWP XPLOR-USD, Ø 48 mm
Rear SuspensionWP XPLOR PDS shock absorber
Ground Clearance355 mm
Seat Height960 mm
ABSNo
Engine TypeSingle-cylinder, 4-stroke
Fuel SystemKeihin EFI, 42 mm throttle body
Front BrakeDisc brake
Rear BrakeDisc brake, 220 mm
Fuel Tank Capacity8.5 liters
Weight (without fuel)106.5 kg
Displacement510.9 cm³
