TECHNICAL DATA - CHASSIS TIGHTENING TORQUES 67

Spoke nipple M3.5 3 Nm (2.2 lbf ft) –

Remaining nuts, chassis M6 15 Nm (11.1 lbf ft) –

Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –

Screw, ball joint, push rod on foot-

brake cylinder

M6 10 Nm (7.4 lbf ft) –

Screw, footbrake cylinder M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, fork stub M6 10 Nm (7.4 lbf ft) –

Screw, front brake disc M6 14 Nm (10.3 lbf ft) –

Screw, rear brake disc M6 14 Nm (10.3 lbf ft)

Loctite

243™

Screw, throttle grip M6 4.5 Nm (3.32 lbf ft) –

Nut, rim lock M8 10 Nm (7.4 lbf ft) –

Remaining nuts, chassis M8 30 Nm (22.1 lbf ft) –

Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –

Screw, bottom triple clamp M8 25 Nm (18.4 lbf ft) –

Screw, brake caliper M8 20 Nm (14.8 lbf ft)

Loctite

243™

Screw, engine bracket M8 30 Nm (22.1 lbf ft) –

Screw, foot brake pedal M8 25 Nm (18.4 lbf ft) –

Screw, handlebar clamp M8 20 Nm (14.8 lbf ft) –

Screw, rear sprocket M8 25 Nm (18.4 lbf ft)

Loctite

243™

Screw, side stand fixing M8 40 Nm (29.5 lbf ft)

Loctite

243™

Screw, tail piece M8 35 Nm (25.8 lbf ft)

Loctite

243™

Screw, top triple clamp M8 25 Nm (18.4 lbf ft) –

Remaining nuts, chassis M10 50 Nm (36.9 lbf ft) –

Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –

Screw, bottom shock absorber M10 45 Nm (33.2 lbf ft) –

Screw, front wheel spindle M10 40 Nm (29.5 lbf ft) –

Screw, handlebar support M10 40 Nm (29.5 lbf ft)

Loctite

243™

Screw, top shock absorber M10 45 Nm (33.2 lbf ft) –

Nut, rear wheel spindle M12x1 40 Nm (29.5 lbf ft) –

Nut, swingarm pivot M12x1 40 Nm (29.5 lbf ft) –

Nut, steering stem M20x1.5 10 Nm (7.4 lbf ft) –
