22 TECHNICAL DATA 186
Fuse 58011109115 15 A
Fuse 58011109125 25 A
Fuse 58011109130 30 A
Fuse 75011088015 15 A
Fuse 75011088010 10 A
Headlight H4 / socket P43t 12 V
60/55 W
Parking light W5W / socket W2.1x9.5d 12 V
5 W
Instrument lights and indicator lamps LED
Turn signal (Duke) RY10W / socket BAU15s 12 V
10 W
Turn signal (Duke R) LED
Brake/tail light LED
License plate lamp LED
22.6 Tires
Front tires Rear tires
120/70 ZR 17 M/C 58W TL
Metzeler SPORTEC M7 RR
160/60 ZR 17 M/C 69W TL
Metzeler SPORTEC M7 RR
The tires specified represent one of the possible series production tires. Additional information is available in the Service section under:
http://www.ktm.com

KTM 690 Duke 2017 Specifications

General

Displacement	690 cc
Compression Ratio	12.7:1
Fuel System	Electronic Fuel Injection
Cooling System	Liquid cooled
Transmission	6-speed
Starter	Electric starter
Lubrication	Forced oil lubrication with 2 oil pumps
Front Suspension	WP upside-down Ø 43 mm
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Seat Height	835 mm
Ground Clearance	192 mm
Wheelbase	1, 466 mm
Fuel Capacity	14 liters
Dry Weight	148.5 kg
Engine Type	Single-cylinder, 4-stroke
Torque	74 Nm @ 6, 500 rpm
Frame	Chromium-Molybdenum steel trellis frame
Rear Suspension	WP monoshock
Front Brake	Brembo four-piston radial fixed caliper, 320 mm disc
Rear Brake	Single 240 mm disc, Brembo single-piston caliper
ABS	Bosch 9M+ two-channel ABS (disengageable)
