KTM 690 Duke 2017 User Manual

28 LIST OF SYMBOLS 202
28.1 Red symbols
Red symbols indicate an error condition that requires immediate intervention.
The immobilizer indicator lamp lights up or flashes red – Status or error message for immobilizer/alarm system.
The oil pressure warning lamp lights up red – The oil pressure is too low.
28.2 Yellow and orange symbols
Yellow and orange symbols indicate an error condition that requires prompt intervention. Active driving aids are also represented by yellow
or orange symbols.
The engine warning lamp lights up yellow – The OBD has detected an emission- or safety-critical fault.
ABS warning lamp lights up yellow – Status or error messages relating to ABS. The ABS lamp flashes if the ABS
mode "SupMot" is enabled.
The TC lamp lights up yellow – The TC or MTC is not available. Contact an authorized KTM workshop. The TC lamp
flashes, if TC or MTC actively engage.
The general warning lamp lights up yellow – An operating safety (warning) message was detected. This is also
shown on the display.
28.3 Green and blue symbols
Green and blue symbols reflect information.
The turn signal indicator lamp flashes green simultaneously with the turn signal – The turn signal is switched on.

KTM 690 Duke 2017 Specifications

General

Displacement	690 cc
Compression Ratio	12.7:1
Fuel System	Electronic Fuel Injection
Cooling System	Liquid cooled
Transmission	6-speed
Starter	Electric starter
Lubrication	Forced oil lubrication with 2 oil pumps
Front Suspension	WP upside-down Ø 43 mm
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Seat Height	835 mm
Ground Clearance	192 mm
Wheelbase	1, 466 mm
Fuel Capacity	14 liters
Dry Weight	148.5 kg
Engine Type	Single-cylinder, 4-stroke
Torque	74 Nm @ 6, 500 rpm
Frame	Chromium-Molybdenum steel trellis frame
Rear Suspension	WP monoshock
Front Brake	Brembo four-piston radial fixed caliper, 320 mm disc
Rear Brake	Single 240 mm disc, Brembo single-piston caliper
ABS	Bosch 9M+ two-channel ABS (disengageable)
