6 CONTROLS 26
V00555-10
Overview of the left combination switch
1 Light switch ( p. 26)
2 Menu switch ( p. 27)
3 Turn signal switch ( p. 27)
4 Horn button ( p. 28)
6.4.2 Light switch
H00381-10
Light switch
1
is fitted on the left side of the handlebar.
Possible states
Low beam on – Light switch in position
A
. In this position, the low beam
and the tail light are switched on.
High beam on – Push the light switch to position
B
. In this position, the
high beam and the tail light are switched on.
Headlight flasher – Push the light switch into position
C
.
