KTM 690 Duke 2017 User Manual

4 VIEW OF VEHICLE 19
1 Tool set ( p. 32)
2 Light switch ( p. 26)
2 Turn signal switch ( p. 27)
2 Horn button ( p. 28)
3 Filler cap
4 Ignition/steering lock ( p. 29)
5 Emergency OFF switch ( p. 28)
5 Electric starter button ( p. 29)
6 Hand brake lever ( p. 24)
7 Chassis number ( p. 20)
8 Fuse box
9 Type label ( p. 20)
10 Engine oil level viewer
11 Foot brake lever ( p. 35)
12 Passenger footrest ( p. 33)

KTM 690 Duke 2017 Specifications

General

Displacement	690 cc
Compression Ratio	12.7:1
Fuel System	Electronic Fuel Injection
Cooling System	Liquid cooled
Transmission	6-speed
Starter	Electric starter
Lubrication	Forced oil lubrication with 2 oil pumps
Front Suspension	WP upside-down Ø 43 mm
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Seat Height	835 mm
Ground Clearance	192 mm
Wheelbase	1, 466 mm
Fuel Capacity	14 liters
Dry Weight	148.5 kg
Engine Type	Single-cylinder, 4-stroke
Torque	74 Nm @ 6, 500 rpm
Frame	Chromium-Molybdenum steel trellis frame
Rear Suspension	WP monoshock
Front Brake	Brembo four-piston radial fixed caliper, 320 mm disc
Rear Brake	Single 240 mm disc, Brembo single-piston caliper
ABS	Bosch 9M+ two-channel ABS (disengageable)
