12 SERVICE WORK ON THE CHASSIS 94
M01433-10
– Shift gear to neutral.
–
Pull the lower chain section with the specified weight
A
.
Guideline
Weight of chain wear measurement 15 kg (33 lb.)
–
Measure distance
B
of 18 chain rollers in the lower chain section.
Info
Chain wear is not always even. Repeat this measurement at different chain posi-
tions.
Maximum distance
B
at the longest
chain section
272 mm (10.71 in)
»
If distance
B
is greater than the specified measurement:
– Change the drivetrain kit.
Info
When the chain is replaced, the rear sprocket and engine sprocket
should also be changed.
New chains wear out faster on old, worn sprockets.
For safety reasons, the chain has no chain joint.
