Technical information
216
Technical information
Conversion table
Lubricants
Only check the oil level when there is a visible loss of oil while the
machine is level.
Transmission oil and lubricant must meet the following requirements
Basic unit: SI - unit Conversion figures:
Length 1 m 39.4 in = 3.3 ft = 1.1 yd = 0.00062 miles (US)
Area
1 m
2
1.2 yd
2
= 10.8 ft
2
= 0.00025 acre = 0.0001 ha
Volume
1 dm
3
(1 l) 61 in
3
= 0.035 ft
3
= 0.22 gallon (lmp) = 0.26 gallon (US)
Speed 1 m/sec 3.6 km/h = 2.24 mph = 3.28 ft/sec
Power 1 N 0.10 kp = 0.22 lbf
Effect 1 kW 1.36 hp = 102 kpm/sec
Mass 1 kg 2.2 lbs = 0.0197 cwt = 35 oz
Torque moment 1 Nm 0.102 kpm = 8.8 lb-in = 0.74 ft. lbs.
Pressure 1 bar
0.01 atm. (kp/cm
2
) = 0.14 psi
RPM
min
-1
= revolutions / min = RPM
Specification
Transmission oil Lubricant
SAE J-2360 80W-90 NLGI GC/LB 2
API GL-4
