BReplacing Fuse
The tractor electrical system is protected from potential
damage by fuses.
A blown fuse indicates that there is an overload or short
somewhere in the electrical system.
If any of the fuses should blow, replace with a new one of
the same capacity.
A Before replacing a blown fuse, determine why the fuse
blew and make any necessary repairs. Failure to
follow this procedure may result in serious damage to
the tractor electrical system. Refer to the
"TROUBLESHOOTING" section of this manual or your
local KUBOTA Dealer for specific information dealing
with electrical problems.
C Protected circuit
Fuse
No.
Capacity
(A)
Protected circuit
ROPS CAB
HST MT HST
(1) 7.5 Alternator
(2) 15 Head lights
(3)
15 Hazard
---
20 Hazard
--- ---
(4) 5 Panel
(5) 5 T/M Controller 1
---
(6)
7.5 Work light
---
15 Work light
--- ---
(7) 5 Brake lamp switch
---
(8) 10
T/M Controller 2
---
OPC Controller
--- ---
(9) 5 Key stop
(10) 30 Starter relay
--- ---
(11) 10 Dome lamp
--- ---
(12) 20 Aircon blower
--- ---
(13) 5 Radio cassette
--- ---
(14) 20 Cigar lighter
--- ---
(15) 7.5 Aircon compressor
--- ---
(16) 30 Wiper
--- ---
(17) 15 Flasher
--- ---
(18) 30 Defogger
--- ---
(19)
Slow
blow
Check circuit against
wrong battery
