SPECIFICATION TABLE [HST Type]
Model
L3240 L3540 L3940 L4240 L4740 L5240 L5740
4WD
Engine
Model
D1703-M-
E2-HST
D1803-M-
E2-HST
V2003-M-
E2-HST
V2203-M-
E2-HST
V2403-M-
E2-HST
V2403-M-TE2-HST
Type Indirect injection vertical, water-cooled, 4-cycle diesel
Number of cylinders 3 4
Total displacement
L
(cu. in.)
1.647
(100.5)
1.826
(111.4)
1.999
(122.0)
2.197
(134.0)
2.434
(148.5)
Bore and stroke mm (in.)
87 x 92.4
(3.4 x 3.6)
87 x 102.4
(3.4 x 4.0)
83 x 92.4
(3.3 x 3.6)
87 x 92.4
(3.4 x 3.6)
87 x 102.4
(3.4 x 4.0)
Net power* kW (HP) 23.9 (32.0) 26.1 (35.0) 28.7 (38.5) 31.3 (42.0) 35.1 (47.0 38.8 (52.0) 42.5 (57.0)
PTO power*
(factory observed)
kW (HP)/
rpm
18.7 (25.0)/
2700
20.9 (28.0)/
2700
23.5 (31.5)/
2700
26.1 (35.0)/
2700
29.8 (40.0)/
2700
33.6 (45.0)/
2600
37.3 (50.0)/
2700
Maximum torque
N-m
(ft-lbs.)
101.7 (75.0)
112.8
(83.2)
123.7
(91.2)
139.7
(103.0)
154.3
(113.8)
180.6
(133.2)
Battery capacity
12V,
RC: 123min,
CCA: 490A
12V, RC: 133 min, CCA: 582A
Fuel Diesel fuel No.1 [below-10 (14 )] Diesel fuel No.2 [above-10 (14 )]
Capacities
Fuel tank
L
(U.S.gals.)
44 (11.6) 50 (13.2) 54 (14.3)
Engine crankcase
(with filter)
L
(U.S.qts.)
5.7 (6.0) 6.7 (7.1) 8.2 (8.7) 9.4 (9.9)
Engine coolant
L
(U.S.qts.)
6.0 (6.3) 7.5 (7.9) 8.2 (8.7)
Transmission case
L
(U.S.gals.)
42 (11.1) 43 (11.4) 45 (11.9)
Dimensions
Overall length
(without 3p)
mm (in.) 2920 (115.0) 3085 (121.5)
3145
(123.8)
3210 (126.4)
Overall width
(min. tread)
mm (in.) 1520 (59.8) 1690 (66.5) 1710 (67.3)
Overall height
(with ROPS)
mm (in.)
2465
(97.0)
2475
(97.4)
2555
(100.6)
2565
(101.0)
Wheel base mm (in.) 1805 (71.1) 1895 (74.6) 1915 (75.4)
Min. ground clearance mm (in.) 355 (14.0) 370 (14.6) 400 (15.7)
Tread
Front mm (in.) 1155 (45.5) 1300 (51.2) 1340 (52.8)
Rear mm (in.)
1200 (47.2), 1300 (51.2),
1385 (54.5), 1480 (58.3)
1285 (50.6), 1435 (56.5), 1530 (60.2)
1325 (52.2),
1430 (56.3)
Weight (with ROPS) kg (lbs.)
1540
(3395)
1645
(3627)
1665
(3671)
1770
(3902)
