Kubota L3540 User Manual

OPERATING THE TRACTOR30
BGlove Box
BSeat Belt
To avoid personal injury:
A Always use the seat belt when any ROPS or
CAB are installed.
A Do not use the seat belt if a foldable ROPS is
down or there is no ROPS.
Adjust the seat belt for proper fit and connect the buckle.
This seat belt is auto-locking retractable type.
BTilt Steering Adjustment
To avoid personal injury:
A Do not adjust the steering wheel while the
tractor is in motion.
Press down the steering wheel tilt pedal, to release the
lock so the steering wheel can be adjusted to one of six
desired positions.
(1) Glove box
(1) Seat belt
(1) Steering wheel tilt pedal (A) "PRESS DOWN"

Kubota L3540 Specifications

General

Drive	4WD
Displacement	111.4 cu in (1.8 L)
Hydraulic System Type	Open center
3-Point Hitch Category	Category I
Tire Size (Rear)	12.4-24
Engine Type	Diesel
PTO Power	29.5 hp
Transmission	Hydrostatic
Number of Gears	3-range
Weight	2601 lbs (1180 kg)
Height	91.7 in (232 cm)
Tire Size (Front)	7-16
