Accessories
100
Accessories
Optional additional equipment does not form part of the standard
scope of delivery, and, in this manual, is indicated by a plus
symbol [+]. Additional equipment is available to order from your
dealer.
Tine saver
For a good swath deposit, both tine legs must run parallel to one
another. This must also be ensured after fitting the tine saver.
Proceed as follows:
Fit one tine saver on each tine.
Check the direction of rotation of the rotor. The nuts must be
attached against the rotor direction.
Check the tine position. The tine legs must be parallel.
If necessary, loosen the screwed connection until both tine legs run
parallel.
Hydraulic single
lift
The optional single lift for the single rotor work position allows the crop
to be retrieved using the left or right rotor.
