3SPECIFICATIONS
SPECIFICATIONS
SPECIFICATION TABLE
Model
RTV-X900 RTV-X1120D
General
Purpose
Worksite
/Orange
Worksite
/Camo
Worksite
/Orange
Worksite
/Camo
Engine
Make D902 D1105
Type 3 cylinders, 4-cycle, diesel, OHV
Displacement L (cu. in.) 0.898 (54.802) 1.123 (68.530)
Horsepower kW (HP) 16.1 (21.6) 18.5 (24.8)
Rated revolution rpm 3200 3000
Low idling revolution rpm 1300 to 1400 1350 to 1450
Fuel Capacity L (U.S.gals) 30 (7.9)
Transmission Continuously variable hydro transmission (VHT)
Wheels, Drive system 4, Rear 2WD or 4WD
Differential lock Standard; foot operated with mechanical holder
Gear selection Hi-Low range forward, neutral, reverse
Brakes
Front / Rear Wet disk brake
Parking brake Rear wheel, hand lever
Steering Hydrostatic power
Suspension
Front
Independent, Dual A-Arm type
Rear
Dimensions
Length mm (in.) 3055 (120.3) 3110 (122.5)
Width mm (in.) 1605 (63.2)
Height, overall mm (in.) 2020 (79.5)
Front tread centers mm (in.)
1240 (48.8) HDWS, ATV
1290 (50.8) Turf
Rear tread centers mm (in.)
Wheelbase mm (in.) 2045 (80.5)
Ground
clearance
front axle mm (in.) 266 (10.5)
rear axle mm (in.) 263 (10.4)
Turning diameter m (ft) 8.0 (26.2)
Max. Rolling weight
(Towing capacity)
kg (lbs.) Rear: 590 (1300), Front: 295 (650)
Payload capacity kg (lbs.) 755 (1664) 725 (1598) 685 (1510)
Weight kg (lbs.) 865 (1907) 895 (1973) 935 (2061)
Gross Vehicle Weight
Rating (GVWR)
kg (lbs.) 1620 (3571)
