PERIODIC SERVICE68
EVERY 200 HOURS
BAdjusting Parking Brake
C Adjusting procedure
1. Park the vehicle on a flat surface.
2. Stop the engine.
3. Jack up the rear wheels.
4. Remove the left rear tire.
5. Remove the mud guard of rubber.
6. Release the parking brake.
7. Loosen the lock nuts.
8. Adjust the cable wire length.
9. Tighten the lock nuts securely.
10.Install the mud guard.
11.Install the left rear tire.
Proper parking brake lever
free play range
1 notch
(1) Parking brake lever
(A) Mud guard
(B) Push rivet
(1) Lock nut
(2) Cable wire
