UNIVERSAL SYMBOLS
As a guide to the operation of your vehicle, various universal symbols have been utilized on the instruments and
controls. The symbols are shown below with an indication of their meaning.
Safety Alert Symbol
Seat Belt (2 point type)
Seat Belt (3 point type)
Diesel Fuel
Fuel-Level
Hourmeter/Elapsed Operating Hours
Engine Coolant-Temperature
Brake Fluid
Parking Brake
Battery Charging Condition
Engine Oil-Pressure
VHT Oil-Temperature
Turn Signal/Hazard
Engine-Stop
Engine-Run
Starter Control
Diesel Preheat/Glow Plugs(Low Temperature
Start Aid)
Differential Lock
Differential Lock Hold
Lift Cylinder-Retract
Lift Cylinder-Extend
Lift Cylinder-Float
Steering Wheel-Tilt Control
Hazard Warning Lights
Headlight
Audible Warning Device
Fast
Slow
4-Wheel Drive-On
Lock
Unlock
