43
TRANSPORTING THE EXCAVATOR ON A TRUCK
3
DANGER
To avoid personal injury or death:
No directional changes should
be made when the excavator is
on the ramp. Should a change
of direction be necessary, drive
off the ramp completely and
make the turn.
When driving forwards or
backwards onto the truck, or
when swinging the upper body,
make sure that neither the
cabin or the gates of the truck
will be damaged.
When the excavator reaches
the point between the ramps
and the truck bed, halt and
then move very slowly until
the excavator reaches the
horizontal position.
Move the excavator onto
the truck only with the
arm completely pulled in.
Otherwise the truck cabin could
be damaged when swinging
around the upper body.
Do not jack up the machine
using its boom to load or
unload the excavator from
the truck. Dangerous situation
could arise.
Transporting on a Truck
3
WARNING
To avoid personal injury or death:
After loading the machine on
the truck, lower the bucket and
dozer onto the truck bed. Lock
the swing frame with the swing
lock pin.
Prepare a platform to load or unload the
excavator. Take following steps when using
ramps.
1. Apply the parking brakes of the truck,
and block the drive wheels from both
sides.
2. Use mounting brackets to secure the
ramp properly. Connect the ramps
directly to the truck bed.
To Next Page
