CRANKCASE SEPARATION
Remove the cam chain tensioner slipper bolt.
Remove the cam chain tensioner slipper and
cam chain.
Remove the two right crankcase attaching
bolts.
Remove the five left crankcase bolts.
Place the crankcase with the left crankcase
down and remove the right crankcase from the
left crankcase.
Remove the gasket and dowel pins.
Remove the crankshaft from the left
crankcase.
