LIGHTS
HEADLIGHT BULB REPLACEMENT
Remove the front upper cover. (
!
2-5)
Disconnect the headlight and turn signal light
wire couplers.
Remove the rubber boot from the bulb socket.
Remove the bulb socket and replace the bulb.
Install the bulb socket, aligning the bulb
socket tab with the groove.
Install the rubber boot.
Install the front cover in the reverse order of
removal.
FRONT POSITION LIGHT BULB
REPLACEMENT
Remove the front upper cover. (
!
2-5)
Disconnect the headlight and turn signal light
wire couplers.
Remove the bulb sockets by turning them
counterclockwise.
Remove the bulbs and replace them with new
ones.
FRONT TURN SIGNAL LIGHT BULB
REPLACEMENT
Remove the one screw attaching the turn
signal light shell and remove the light shell.
Remove the turn signal fixer two screws.
Remove the bulb protector screw.
Remove the bulb and replace with a new one.
TAILLIGHT/REAR TURN S IGNAL LIGHT
BULB REPLACEMENT
Remove the rear protective cover. (
!
2-3)
Remove the two screws attaching the rear
light shell and remove the light shell.
Remove the bulbs and replace with new ones.
The installation sequence is the reverse of
removal.
