THERMOSTAT
THERMOSTAT REMOVAL
Remove the seat, met-in box and center
cover.
Drain the coolant.
Disconnect the thermosensor wire from the
thermosensor.
Disconnect the water hose from the
thermostat housing.
Disconnect the air vent tube from the
thermostat housing.
Remove the mounting bolt and the
thermostat housing from the cylinder head.
Remove the two bolts and separate the
thermostat housing halves.
Remove the thermostat from the thermostat
housing.
To Next Page
