13. FUEL SYSTEM/CARBURETOR/
FUEL PUMP/ FUEL TANK
13-15
Bet & Win 1 25/1 50
FLOAT CHAMBER ASSEMBLY
Install the main jet.
Install the slow jet.
Install the pilot screw.
Install the float valve, float and float pin.
Float Valve
Float
Float Pin
Pilot Screw
Slow Jet
Main Jet
• Be sure to record the rotating turns
when it is removed.
＊
