19. SWITCHES/HORN/FUEL UNIT/THERMOSTATIC SWITCH
/TEMPERATURE GAUGE/INSTRUMENTS/LIGHTS
19-1
Bet & Win 1 25/1 50
ELECTRICAL EQUIPMENT LAYOUT
Turn Signal Switch
Stop Switches
Horn Button
Headlight
Dimmer Switch
Fuel Unit
Starter Button
Horn
Ignition Switch
Auto Bystarter
Thermosensor
Instruments
Thermostatic
Switch
Headlight
Switch
