the throttle valve with the throttle stop screw.
Tighten the carburetor cap.
After installation, perform the following
adjustments and inspections.
• Throttle cable free play (
ð
3-11)
• Idle speed adjustment (
ð
3-8)
Install the met-in box.
CARBURETOR REMOVAL
Remove the met-in box. (
ð
12-4)
Remove the air cleaner by removing the air
cleaner band screw and attaching bolts.
Disconnect the fuel tube.
Loosen the drain bolt to drain fuel from the
carburetor.
Disconnect the auto bystarter wire connector.
Remove the two carburetor lock nuts.
Remove the carburetor.
