11. CARBURETOR
11
-
8
ZX / SCOUT
50
FLOAT CHAMBER
Remove the two float chamber screws and the
float chamber.
Remove the screw and O-ring.
Remove the float pin, float and float valve.
FLOAT/FLOAT VALVE INSPECTION
Inspect the float for damage or fuel inside the float.
Check the float valve seat for wear or damage.
Auto Bystarter
Float
O
-
ring
Set Plate
Float Pin
Screws
Screws
