2LY/2LZ
2-4-3
(3) Self diagnostic codes indication (Animation)
Click the icon to play the animation of the indicator combinations.
Right-click an indicator, then select Playback and Play to play the animation repeatedly.
To play the animation, you have to install Adobe Flash Player and Adobe Reader (Version 6.01 or more) to your PC.
If the animation is not displayed, you should get the latest version from Adobe site (http://www.adobe.com/downloads/).
Indication Contents
Control PWB EEPROM error
Paper feeder communication error
Main motor error
PF paper feed motor error (Paper feeder 1)
PF paper feed motor error (Paper feeder 2)
Polygon motor (laser scanner unit) error
Broken fuser heater lamp wire
Abnormally high fuser thermistor temperature
To Next Page
