2LY/2LZ
1-5-33
(4) Direction of installing the left and right cooling fan motors
When detaching or refitting the left and/or right cooling fan motors, be careful of the airflow direction (intake or exhaust).
Figure 1-5-45
Left cooling
fan motor
Right cooling
fan motor
Exhaust
Intake
