2LY/2LZ
1-1-3
1-1-2 Parts names
(1) Overall
Figure 1-1-1
2
3
4
1
7
9
6
10
11
12
13
14
8
5
1. Top cover
2. Paper stopper
3. Top tray
4. Operation panel
5. Right side cover
6. Cassette
7. Front cover
8. MP tray
9. Sub tray
10. Optional interface slot cover
11. USB interface connector
12. Rear cover
13. Power cord connector
14. Power switch
