Kyocera FS-2000D User Manual

Using the Operation Panel
ADVANCED OPERATION GUIDE 2-83
By default, resource protection is deactivated.
1
Press [Menu].
2
Press ? or @ repeatedly until Others >
appears.
3
Press B.
4
Press ? or @ repeatedly until >Resource
Prot. appears.
5
Press [OK]. A blinking question mark (?)
appears.
6
Press ? or @ to select Permanent or Perm / Temp (Permanent/
Temporary) for resource protection.
7
When the desired resource protection is displayed, press [OK].
8
To exit the menu selection, press [Menu].
Alarm (Buzzer) Setting
You can set an alarm sound in addition to the message displayed when the
paper supply is exhausted, or when paper jamming occurs. This setting is
useful, for example, when the printer is located some distance from the
user.
The audio alarm is set to On when leaving the factory. If the alarm is set to
Off, it will not sound.
1
Press [Menu].
2
Press ? or @ repeatedly until Others >
appears.
3
Press B.
4
Press ? or @ repeatedly until >Buzzer >
appears.
5
Press B.
Others >
>Resource Prot.
Permanent
>Resource Prot.
?
Permanent
Others >
>Buzzer >

Kyocera FS-2000D Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	64 MB
Maximum internal memory	576 MB
Total input capacity	500 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Media weight (tray 1)	60-120 gsm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Custom media sizes	148 x 210 mm - 216 x 356 mm
Power requirements	220 - 240 V
Networking features	Ethernet/Fast-Ethernet
Maximum duty cycle	150000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	9 W
Power consumption (printing)	400 W
Power consumption (PowerSave)	4 W
Certification	TÜV/GS, CE, PTS

Weight and Dimensions

Dimensions (WxDxH)	382 x 394 x 285 mm
