L-Acoustics L Series User Manual

Specications
Specications
L2 specications
Description 16-channel active progressive curvature WST 10° enclosure: 4 × 12" LC + 8 ×
10" LF + 8 × 3" HF amplied by LA7.16 / LA7.16i
Usable bandwidth 45 Hz - 20 kHz
Maximum SPL
1
entire enclosure module 1 only
2
155 dB ([L2 70]) 147 dB ([L2 70])
Nominal directivity (-6 dB) horizontal: 70° / 110° symmetric or 90° asymmetric
vertical: 10°
Transducers LC:
3
4 × 12" neodymium cone drivers
LF: 8 × 10" neodymium cone drivers
HF: 8 × 3" neodymium diaphragm compression drivers
Acoustical load LC: bass-reex, L-Vents
LF: bass-reex, L-Vents
HF: DOSC waveguide, L-Fins
Nominal impedance LC: 8 Ω
LF: 8 Ω
HF: 8 Ω
Connectors IN: 37-point male connector (32 points used)
Rigging and handling ush-tting 4-point captive rigging system compatible with L2D
4 handles
4 ground runners
Weight (net) 158 kg / 348 lb
Cabinet premium grade Baltic beech and birch plywood
Front coated steel grill
acoustically neutral 3D fabric
Rigging components high grade steel with anti-corrosion coating
Finish dark grey brown Pantone 426 C
IP IP55
1
Peak level measured at 1 m under free eld conditions using pink noise with crest factor 4 (preset specied in brackets).
2
Provided to enable fair comparison with one enclosure of a constant or variable curvature system.
3
LC: Low frequency Cardioid
124 L2 owner's manual (EN) version 2.0
