Specications
L2-LASERMOUNT specications
Description
Lasermount for L2 and L2D
W
eight (net)
1 kg / 2 lb
Material
high grade steel with anti-corrosion coating
L2-LASERMOUNT dimensions
205
mm
/ 8.1
in
123
mm
/ 4.8
in
85
mm
/ 3.3
in
136
L2
owner's
manual
(EN)
version
2.0
135
137
