Electro-acoustical description
Adjustable ns
Horizontal directivity can be set independently on the four Panex modules of L2 and the top two Panex modules of
L2D using the push-push mechanism of the ns in combination with the specic electronic presets. There are four possible
settings: 70° / 110° symmetric or 90° asymmetric (35°/55° or 55°/35°).
The bottom two Panex modules of L2D have a xed progressive directivity pattern from 110° to 140°.
The Panex modules are equipped with a push-push mechanism: push on the retracted n to deploy it, push on the
deployed n to retract it.
Risk of breaking the n hooks
Do not use excessive force when deploying the ns.
Apply pressure on the external side of the n on both the upper and lower areas at the same time.
Within a line source, combine L2 and L2D with custom directivity settings to improve the coverage of the audience
geometry.
L2 owner's manual (EN) version 2.0 15
