Specications
L2D-CHARIOT specications
Description
Chariot for one L2D
W
eight (net)
33 kg / 72 lb
Material
high grade steel with anti-corrosion coating
L2D-CHARIOT dimensions
322
mm
/ 12.7
in
346
mm
/ 13.6
in
608
mm
/ 23.9
in
1098
mm
/ 43.2
in
L2
owner's
manual
(EN)
version
2.0
139
138
140
