Connection to LA amplied controllers
Connection to LA amplied controllers
Refer to the Amplication reference technical bulletin for the latest information on compatibility with amplied
controllers and cabling schemes for all enclosure types.
Enclosure drive capacity per amplied controller
LA7.16/LA7.16i
per output / total
L2 1
L2D 1
Cabling schemes for L2 / L2D
Refer to the cabling schemes to connect the enclosures to different types of output congurations.
16-channel connector output
SC32
LA7.16i terminal block output
2−
2+
1−
1+
A
B
C
D
3+
3−
4+
4−
H
G
F
E
7+
7−
8+
8−
6−
6+
5−
5+
J
K
L
M
S
R
P
N
10−
10+
9−
9+
T
U
V
W
11+
11−
12+
12−
b
a
Y
X
14−
14+
13−
13+
c
d
e
f
15+
15−
16+
16−
k
j
h
g
SC32 BE
custom patch
86 L2 owner's manual (EN) version 2.0
