Installing a laser inclinometer
Installing a laser inclinometer
L2-LASERMOUNT
L2-LASERMOUNT can be used to secure a laser inclinometer vertically or horizontally
, using the L-Acoustics T
ech T
oolcase
II accessories.
With LASER-MAGPLATE
Mount the inclinometer on the LASER-MAGPLATE:
Position the magnetic LASER-MAGPLATE on L2-LASERMOUNT:
V
ertical mount
Horizontal mount, with the bracket
With screws
V
ertical mount
L2
owner's
manual
(EN)
version
2.0
143
142
144
Table of Contents
